#10GS-SZ8-FB-PET-DC-10#
Grooved Eight-Thread Explosion-Proof Zipper
A shielded track keeps every seam aligned through harsh handling.
The #10 grooved eight-thread model is designed for heavy bulk bags, warehouse storage, and high-load textile packaging. An integrated groove in the tape positions the eight stitching lines and separates them from direct slider friction. Four-needle eight-thread sewing and dual-layer, dual-track polyester coil teeth improve seam alignment, flatness, and load distribution through repeated handling and cleaning.
Key Features
- ✓Integrated groove protects stitching from wear
- ✓Eight-thread edge lock prevents tearing
- ✓Double-layer teeth resist burst and chain separation
- ✓Improved flatness and centered seam alignment
Specifications
| Color | Black (custom colors available) |
|---|---|
| Length | 100–3000 mm, ±3 mm tolerance (custom) |
| Profile | #10 heavy-duty profile |
| Material | High-density polyester tape |
| Tape width | 44.0±0.5 mm |
| Slider chamber | H 3.1–3.2 / W 9.25–9.35 mm |
| Wide tape option | 46 mm |
| Zipper thickness | 3.1±0.05 mm |
| Closed chain width | 9.20±0.05 mm |
Applications
- Large bulk and container bags
- Industrial storage bags
- Heavy-duty trolley cases
- Equipment and logistics covers
